Pulse N Male Connector CNT400/LMR400/RG213/RG214- Solder/Clamp

Pulse Connectors are high quality and used by industry alike.

Description

Straight Cable Plug Clamp
Suits Cables: LMR400 CNT400 RFI-400-UF RG213 RG214
Technical Data Electrical
Impedance 50 Ohm
Max Frequency 11 GHz
Mechanical & Environmental Data
Centre contact Solder
Outer Contact Clamp
Mating 5/8″ – 24 threaded coupling
Durability 500 matings
Coupling nut retention 100lbs Max
Cable Retention 40 lbs min
Tempreture Range -65° to 165° C
Vibration MIL-STD-202 Test Cond B
Salt Spray MIL-STD-101 Test Cond B
Thermal Shock MIL-STD-107 Test Cond B
Material Data Parts Material
Connector Body Brass Silver
Centre contact Brass Gold
Insulation Teflon –
Gasket Silicone Rubber –
Crimp Ferrule Anneald Copper Silver

Installation Sheet
